Description
The table refers to the maximum distance applicable between LED module rows in relation to the can depth.
VBX Diamond 2 LED Modules -24V
LED modules at 24V for uniform and efficient lighting even at high thicknesses thanks to the innovative lens design. New technology to achieve high efficiency. High beam angle 175°. IP67 protection rating for outdoor installation. Also suitable for indoors thanks to CRI>80. For illuminated signs, channel letters, light boxes, backlighting; for lighting, advertising, decoration. Equipped with double-sided adhesive and screw hole.
Ideal for depths from 50 mm to 100 mm
Additional information
| Full Packaging | 100 modules. Price for single module. |
|---|---|
| Input voltage | 24V |
| Power | 0,72 W |
| Lumen [lm] | 105-115-117 Lm 300K-4000K-6500K |
| Color CCT | 3000K- 4000K- 6500K |
| Nominal beam angle [°] | 170° |
| Size | 50×16 xH11 mm |
| IP | 67 |
| Pitch | 180 mm |
| Warranty | 5 Years |
| Energy Efficiency Class | D |
